Bob Builds the Wizkids Giant Atlas Rhinoceros Beetle - Paint Guide

Bob Builds the Wizkids Giant Atlas Rhinoceros Beetle - Paint Guide

Wheels and Wings Hobbies - Miniature Paint Guide

Bob Builds the Wizkids Giant Atlas Rhinoceros Beetle

Wizkids - Pre-Primed Miniature - Full Paint Guide

? BEETLE

Bob picked up the Wizkids Giant Atlas Rhinoceros Beetle - unfortunately no longer available - and painted it using a layered metallic airbrushing approach that builds genuine depth and colour variance across the carapace. No single colour, no flat coat - instead a sequence of thinned metallics, selective washes and a careful final unifier that holds the whole thing together without killing the shine.

The model comes pre-primed from Wizkids, so no additional primer step is needed - you go straight to paint.

Wizkids Giant Atlas Rhinoceros Beetle - hero shot

Bob's Wizkids Giant Atlas Rhinoceros Beetle.

Rhinoceros Beetle - pose 2
Rhinoceros Beetle - pose 3

How Bob Painted It

Full step-by-step breakdown. All products in stock at Wheels and Wings unless noted.

AIRBRUSH SETUP

Thinning and Flow - Bob's Setup and Alternative

All airbrushing in this build uses Vallejo Airbrush Thinner with a drop(s) of Flow Improver added to the mix until tip dry is at a manageable level. The Army Painter Airbrush Medium is a convenient pre-mixed alternative that combines thinner and flow improver in one bottle.

Bob's setup - Vallejo
Vallejo Airbrush Thinner 200ml (71161) - primary thinner for all steps
Vallejo Airbrush Flow Improver (71362) - add one drop to the mix at a time until tip dry is manageable
Alternative - Army Painter
Army Painter Airbrush Medium (AW2001) - thinner and flow improver pre-mixed in one bottle; convenient single-product alternative
STEP 1

Gloss Black Base - Thinned Heavy to Wash Into Recesses

Vallejo Gloss Black thinned heavily and airbrushed over the whole model. At this dilution the paint largely drops into the recesses of the carapace detail, almost acting as a glossy wash - but it also grabs to the high points of the surface. The gloss base is what gives the subsequent metallic layers their depth and reflectivity.

Vallejo Model Color Gloss Black (70861) - thinned heavily; floods recesses and grabs to high points simultaneously
STEP 2

Hydra Turquoise - Sparse Green Depth

Vallejo TMM Hydra Turquoise misted sparingly over the black base to build green depth into the carapace. The coverage is deliberately light - small sprays, check the effect, decide whether to stop or add another pass. The goal is colour suggestion, not full coverage.

Vallejo TMM Hydra Turquoise (77132) - misted sparingly over black base for green depth; build up in small passes
STEP 3

Rusty Metal - Catching High Points from Distance

Vallejo TMM Rusty Metal airbrushed from roughly double the usual spraying distance. At that range the paint catches only the highest points of the surface detail and falls off toward the recesses, creating a natural tonal shift that reads differently under different light sources and from different angles. The key is finding the right distance - far enough that the paint hits only the peaks, close enough that it doesn't dry mid-air before reaching the model.

Vallejo TMM Rusty Metal (77178) - airbrushed from double usual distance to catch high points only; creates metallic tonal shift
STEP 4

Black Wash - Re-Establishing Carapace Separation

Vallejo Model Wash Black applied specifically into the deep recesses where the carapace sections meet. The previous metallic steps can muddy fine separation lines - this wash re-establishes and emphasises that detail, bringing the carapace definition back to where it needs to be.

Vallejo Model Wash Black (76518) - applied into deep carapace recesses only; re-establishes separation detail muddied by metallic steps
STEP 5

Old Gold and Blue Grey Wash - Colour Variance and Unifier

Two things happen in this final step. Old Gold is applied carefully and almost dry-brushed into the recesses, horns, and legs - particularly near the feet. Adding another metallic colour variance builds believability and prevents the carapace reading as a single uniform tone. The more colour temperatures at play, the more convincing the result.

Blue Grey wash is then applied carefully over the entire beetle to unify all the colours and hues across the carapace. Thinned enough that it doesn't knock back the metallic quality of the surface - it sits on top as a colour filter, pulling the green, rust, gold and black into a single coherent read.

Vallejo Mecha Color Old Gold (69060) - dry brushed carefully into recesses, horns and legs especially near feet; adds metallic colour variance
Vallejo Model Wash Blue Grey (76524) - thinned wash over the entire beetle; unifies all colours without killing the metallic quality
BASE

Garden Assortment, Basing Glue and Mod Podge

Bob sourced the base materials from his own garden - an assortment of natural debris fixed down with Army Painter Basing Glue and Mod Podge. Mod Podge is a craft store product not carried at Wheels and Wings, but widely available at any craft retailer.

The Finished Model

Follow Bob's work at bob_builds_models on Instagram.

Rhinoceros Beetle - pose 2
Rhinoceros Beetle - pose 3

All paints and supplies used in this guide are in stock at Wheels and Wings Hobbies in Toronto, available online with Canada-wide shipping.
